HS2000 / Springfield XD

Original 9mm HS2000 pistol, circa 2000. Note that it has no accessory rails below the barrel

Springfield eXtreme Duty / XD pistol, caliber 9mm

Springfield eXtreme Duty / XD Tactical pistol with 5 inch barrel, caliber .40S&W

Springfield eXtreme Duty / XD Sub-compact

Partial disassembly of HS2000 pistol

	XD Sub-compact	HS2000 / XD 4"	XD Tactical
Type	Single Action semiautomatic
Caliber(s)	9x19mm, .357SIG, .40SW, .45GAP, .45ACP
Weight unloaded	590 g	650 g	890 g (925g in .45acp)
Length	159 mm	180 mm	203 mm (205mm in .45acp)
Barrel length	76 mm	102 mm	127 mm
Magazine capacity	10 (9mm) or 9 (.40) rounds	16 (9mm), 12 (.357 or .40), 9 (.45GAP) or 13 (.45ACP) rounds	16 (9mm), 12 (.357 or .40), 9 (.45GAP) or 13 (.45ACP) rounds

HS2000 pistol has been developed by Croatian IM Metal company for Croatian army during late 1990s. Production of the 9mm HS2000 started in 1999, with the first pistols being delivered to the Croatian army the same year. In 2000 these pistols first appeared in the USA, initially imported under their original name. However, in late 2001 the Springfield Armory Company of Genseo, Illinois, became the sole importer of HS2000 pistols in USA. Springfield offers a slightly improved version of HS2000 as the Springfield XD (eXtreme Duty pistol), and by now these pistols (still made in Croatia) are available in a variety of sizes, calibers and finishes.
After several years of aggressive sales, these pistols gained good reputation and serious following among American shooters, and by now several police departments in USA either issue these pistols on regular basis or approve them for personal purchase by police officers.

The HS2000 is short-recoil operated, locked-breech pistol with a polymer frame. The barrel locks to the slide with a single large lug which engages the ejection port. Unlocking and locking is controlled by a cam-shaped lug which interacts with a steel insert pinned to the frame. If the insert becomes worn or damaged, any competent gunsmith can easily replace it. The dual return spring arrangement is of the captive type; when assembled, the front of a spring guide rod projects slightly forward from the front of the slide; Springfield advertising literature calls this a "muzzle protector", but the original text of patent WO02059539, published in August 01, 2002 and granted to the Croatian design team, describes the reason for this feature as to "enable firing the bullet when the pistol is pushed towards someone's back". This is "necessary" because HS2000, as almost any other modern pistol, has a disconnector safety that does not permit the release of the striker if the slide is not fully closed and locked to the barrel, and such situation can be easily encountered in circumstances described in the quote. The trigger is single-action, also described in the advertising literature as Ultra Safety Assurance system. The pistol is striker fired, with the firing pin cocking indicator made in the form of a pin which protrudes from the rear of the slide when the gun is cocked. There are no manual safeties on the HS2000, but several automatic safeties are present, such as a firing pin block, a trigger safety and a grip safety. The sights are fixed, with the rear being dovetailed to the slide. Current production pistols also have an integral accessory rail on the frame, below the barrel; early production pistol had no such feature. The double-stack magazines are made of steel and hold 15 rounds of 9mm ammunition for original HS2000 pistols. Magazine release buttons are duplicated on either side of the frame, at the base of the trigger guard. Croatian military issue pistols have a black finish, while commercial pistols may have either black or a "military green" frame with a black or polished steel slide. Commercial models are also available in "Compact" and "Tactical" versions, with barrel lengths of 76mm (3 inch) or 127mm (5 inch) respectively, and in a variety of calibers.

Read more »

PHP MV 9 and PHP VM 17



PHP MV-9 pistol

PHP VM-17 pistol

Data for PHP MV 9 pistol

Type	Double Action semiautomatic
Caliber(s)	9x19
Weight unloaded	985 g
Length	195 mm
Barrel length	105 mm (140 mm for PHP VM 17)
Magazine capacity	15 rounds

PHP (Prvi Hrvatski Pistolj - first Croatian pistol) is a somewhat strange weapon which was hastily developed in Croatia during its war for independence in early 1990s. Production and quality of this pistol (which was produced in at least two versions, short-barreled PHP MV 9 and long-barreled PHP VM 17) was sporadic, and it was soon replaced in production and use by much better and more modern HS 2000 pistol.
By design, this pistol represents a mix between Beretta 92 and Walther P38 pistols. The basic short-recoil operated action with vertically tilting locking piece is similar to both pistols, the general appearance of the open-top slide is close to the Walther but the single return spring below the barrel is apparently an Italian influence. Trigger is of traditional double action type, and the safety consists of a manual decocking lever, located on the left side of the grip frame. Magazines are double-stack and hold 15 cartridges.

Read more »

MAB PA-15

9mm MAB Model R pistol, the 8-shot predecessor / prototype to PA-15

MAB  PA-15 pistol, left side

MAB PA-15 pistol, right side

MAB PA-15 Target / PAP F-1 match pistol

Type: Single Action semiautomatic
Chamber: 9x19 mm Luger/Parabellum
Weight unloaded: 1070 g
Length: 203 mm
Barrel length: 117 mm (140 mm for PAP F-1)
Capacity: 15 rounds

When, in late 1970s  production of the 9mm M1950 pistols ceased, the French army obtained small numbers of commercially available MAB P15 pistols, also in 9x19. These pistols were never adopted for general army service, but saw some use in the hands of French Naval Commando units, Military police and Marines. The long-barreled version of the P15 was used in very small numbers by the French army shooting teams under the designation of PAP F-1.
The MAB P15 pistol (also known as the PA-15, for Pistolet Automatique 15) was developed by the Manufacture d'Armes Automatiques de Bayonne (MAB) during the early 1970s based on the earlier 9x19 MAB Modele R Para pistol, which was originally created for the French army trials of late 1940s. The P15 saw minor use by the French military and was also widely exported for commercial sales. Production ceased in the late 1980s, and while there were rumors of this pistol being made in the former Yugoslavia, it seems that this venture never went past talks or experimenting. The P15 was a solid, accurate pistol with large magazine capacity and low felt recoil. Probably the only “drawback” of this system was its single action trigger, a slightly old-fashioned setup by the standards of the time.



The MAB P15 is a delayed-blowback pistol with a rotary barrel. It uses a variant of the Savage-Searle system, originally developed in the USA in 1905-07. The breech part of the barrel has two lugs, one at the top and one at the bottom. The lower lug is engaged in the perpendicular cut made in the frame insert, and allows the barrel to rotate but not recoil. The upper lug follows a curved track cut in the inner surface of the slide. When the gun is fired, the pressure of the propellant gas forces the cartridge case back against the slide. The recoil of the slide, via the cam track, forces the barrel to rotate to the right; at the initial stages of the shot, when the bullet is still in the barrel and pressure is high, the rotation of the barrel and, subsequently, the opening of the slide, are opposed by the inertia of the barrel plus torque created by the bullet following the rifling. As soon as bullet leaves the barrel, the torque force disappears and the slide forces barrel to rotate all the way through the cam arc. There’s a straight cut in the slide which then allows it to go back without any further resistance from the barrel. The trigger is single-action, with an external hammer and a manual, frame mounted safety. There is also an automatic magazine safety. Magazines are of double stack design, and hold 15 rounds. Sights are fixed, with the rear being dovetailed to the slide. Manual safety was a lever at the left side of the frame, above the grip panel. To put on safety, push the lever up; to set to “Fire”, pull the lever down

How to disassemble MAB PA-15 pistol: 1) remove the magazine by pressing the magazine release button; 2) check that the chamber is empty; 3) cock the hammer 4) pull the slide rearward for about 6mm (1/4 of an inch), to align the rear end of a slide stop with the disassembly notch in the slide; 5) pus the slide stop pin inwards from the right, and then pull it out completely from the left; 6) pull the slide forward and out of the frame; 7) turn the slide upside down, and push the base of return spring guide slightly forward, and then pull it up at out of the slide; 8) move the barrel forward until it completes its rotation in the slide (about 8mm), then pull it out of the slide.
Reassemble in reverse order.

Read more »

MAS / MAC mle. 1950

Mle.1950 pistol, right side

Mle.1950 pistol, left side

Mle.1950 pistol, disassembled

Type: Single Action
Chamber: 9x19mm Luger/Parabellum
Weight unloaded: 860 g
Length: 192 mm
Barrel length: 112 mm
Capacity: 9 rounds

At the end of World War Two, the French army had a mixed stock of pistols. The Police were armed with an even wider array of various pocket pistols made by French companies, as well as some foreign pistols, mostly imported from Belgium and made by FN.
Recognizing the need for a more modern and powerful military pistol (which would fire NATO-standard 9x19 ammunition also suitable for sub-machine guns), in late 1946 the French army issued a requirement for a new 9mm military pistol. Several designs were tested and in 1950 the army adopted a design from the state-owned MAS arsenal based in St.Etienne (Manufacture d'Armes de Saint-Etienne). This pistol, known as the Mle.1950 or M1950 was broadly based on the pre-war M1935 pistol, strengthened to use the more powerful 9x19 ammunition which also was intended for MAT-49 sub-machine guns. These pistols were made by two state-owned armories, MAS and MAC (Manufacture d'Armes de Chatellerault) between 1956 and 1978. During their lifetime, many pistols were factory refurbished and returned for service. In general, the troops liked these guns for their strength and durability; accuracy was less than ideal, but still acceptable for a military pistol.
The M1950 pistol was manufactured by the MAC (Chatellerault) factory between 1956 and 1963, and by the MAS (St.Etienne) factory between 1961 and 1978.

The Model 1950 pistol (also designated as Mle.1950 or M1950) is short-recoil operated, locked-breech weapon of all-steel construction. It uses Browning-type locking with the barrel engaging the slide via two lugs made on the top of the barrel, just ahead of the chamber. Unlocking and locking is controlled by the swinging link, which connects the barrel to the frame. The trigger is single-action, with an exposed hammer and a manual safety mounted on the slide. The hammer / sear module is made as a single, easily removable unit, following the 1935-vintage Charles Petter patents. Magazines are of single stack variety, and the pistol is fitted with an automatic magazine safety; the sights are fixed. Manual safety is lever at the left side of the slide, next to the hammer. To put on safety, push the lever up; to set to “Fire”, pull the lever down

How to disassemble M1950 pistol: 1) remove the magazine by pressing the magazine release button; 2) check that the chamber is empty; 3) pull the slide slightly back and hold it there; 4) while holding the slide slightly retracted, push in the slide stop pin from the right, then pull the slide stop out of the frame to the left; 5) release the slide carefully and then push it forward and out of the frame; 6) put the slide upside down, and remove the return spring with its guide; 7) remove the barrel from the slide; 8) pull the hammer unit up and out of the frame.
Reassemble in reverse order.

Read more »

Mle. 1935A and 1935S

Mle. 1935A



Mle. 1935A

Mle. 1935S

Type: Single Action
Chamber: 7.65x22mm Longue
Weight unloaded: 790 g
Length: 188 mm
Barrel length: 105 mm
Capacity: 8 rounds

The Modele (Mle.) 1935 pistol had been developed by Swiss designer Charles Petter for French company SACM around 1935, and in 1935 this pistol had been adopted by French military as Mle.1935. Initial production began in 1936, and due to low rate of production the pistol had been slightly redesigned in 1938, to simplify manufacture. New model had been designated as Mle.1935S, while original model became Mle. 1935A. Most noticeable change was in the shape of the backstrap and in the lenght of the frame, and in the fact that in Mle. 1935S muzzle protruded from the slide, while in Mle. 1935A muzzle was flush with the slide. Mle. 1935 was official French sidearm until 1950. It was a good pistol, with main drawback being somewhat weak ammunition of 7.65mm caliber. Mle. 1935A was quite an elegant weapon, while Mle. 1935S had much more simplified look. The Mle.1935 had been manufactured by MAC, MAS, SAGEM and SACM factories.

Technically, the Mle.1935 is a further development of the Colt-Browning M1911 pistol. Mle. 1935 uses same locked breech, swinging link operated locking with single locking lug on the top of the barrel (in the Mle. 1935S the locking lug was formed on the slide, and on the top of the barrel there was a recess). The hammer and lockwork was designed as a single assembly, removable for cleaning maintenanse (first originated in Soviet TT pistol of 1930). This unit contained hammer, sear and mains spring. The slide mounted safety locked the firing pin when engaged. Sights were fixed and magazine single stack, holding 8 rounds.

Read more »

Manufrance Le Francais

Manufrance Le Français Pocket pistol, original model in 6.35mm caliber



Manufrance Le Français Policeman pistol, caliber 6.35mm

Manufrance Le Français Armee pistol, caliber 9mm



Manufrance Le Français Armee pistol, with barrel tipped up for loading. Barrel latch lever is visible above the trigger

Manufrance Le Français pistol in 7.65mm Browning (.32ACP) caliber, model of 1950. Note that it has slide serrations and spent cartridge extractor, unlike all previous models

Diagram from original French patent, issued to Manufrance, showing the typical recoil spring arrangement of all Le Français pistols. The lever which connects the slide with return spring is marked with grey color. Two such levers are concealed under both side grip panels.

	Le Français Policeman, 1922	Le Français Armee, 1928	Le Français 7,65mm, 1950
Type	Double Action Only semiautomatic
Caliber(s)	6.35x16SR / .25 ACP	9x20SR Browning Long	7,65x17SR / .32 ACP
Weight unloaded	350 g	960 g	630 g
Length	157 mm	202 mm	152 mm
Barrel length	87 mm	127 mm	83 mm
Magazine capacity	7 rounds	8 rounds	8 rounds

Le Français (Le Francais) semi-automatic pistols were originally developed in 1913 by French small arms designer Etienne Mimard, who at the time worked for the French company Manufacture Française d’Armes et de Cycles de Saint-Étienne, which was later renamed to Manufrance. This was simple and unorthodox weapon, which was put into production in 1914 as a pocket-type personal defense sidearm, chambered for then-popular 6.35mm Browning (.25ACP) cartridge, and designated as "Le Francais" (the French). In 1922 the basic "Pocket" model was fitted with enlarged barrel and a spare round loop at the base of the magazine, and became the Le Français "Policeman" pistol. this weapon was manufactured by Manufrance until 1968, and sold to various police units in France, as well as to general public. In 1928 Manufrance introduced the biggest of the Le Français series pistols, known as the Armee (Army) model. It was submitted for French army trials but eventually lost. Nevertheless, the Le Français Armee pistol, chambered for 9mm Browning Long ammunition, was put into production, which lasted until 1939, with slightly less than 5000 Army model pistols made. Since 1950 Manufrance also manufactured a 7,65mm Browning caliber pistol under the same label, which was sold mostly for civilian markets. This model was the only one of the whole "Le Français" series to have slide serrations, and it was manufactured by Manufrance between 1950 and 1965.

All Manufrance Le Français pistols used simple blowback action. The return spring was located vertically in the grip, ahead of the magazine well. It was connected to the slide with dual rocking levers, located below each grip panel. When slide recoiled, these levers pivoted back and compressed the return spring. The barrel was connected to the frame by the pivot below the muzzle and by the simple catch below the chamber (breech). There was no extractor, and spent cartridges were thrown out of the barrel by gas pressure. Dud or unfired cartridges were extracted manually, often with the help of the cleaning rod or other similar object. Since there was no normal way to manually cycle the slide, user had to release the barrel lock (push the lever, located above the trigger on the right side of the frame), and then tip the rear part of the barrel up, exposing its breech. Once barrel was tipped up, user was able to load cartridge directly into the chamber or manually extract unfired cartridge. The only standard way to fully load the gun was to manually load the round into the chamber and then insert the full magazine. To facilitate faster reloading, some models were fitted with spare cartridge loop at the magazine base. This loop held additional cartridge which user had to hand load into the chamber before inserting the fresh magazine. Magazines were of single stack design, magazine release was located at the base of the grip. The trigger was of double-action only type, striker fired. No manual safety was provided. The 7,65mm  Le Français pistols of post-WW2 manufacture were modified with addition of conventional external extractor and slide serrations, which allowed for more conventional loading and unloading procedure. The tipping barrel, however, was retained.

Read more »

Lahti L-35 and Husqvarna M/40



Lahti M-35 - Finnish military model



Husqvarna M/40 - Swedish military model (simplified L-35, manufactured under license)



Husqvarna M/40 - major parts

Data for original Lahti L-35 pistol

Type: Single Action
Chamber: 9x19mm Luger/Parabellum
Weight unloaded: 1220 g
Length: 245 mm
Barrel length: 107 mm
Capacity: 8 rounds

The L-35 pistol had been developed by the Finnish designer Aimo Lahti and manufactured by Finnish company VKT from 1935 until 1985 or so. It was adopted as a standard sidearm for Finnish army in 1935. In 1940, Sweden purchased a license for Lahti pistol, simplified it and began production as a Husqvarna M/40 pistol. Due to simplification and poor quality of steel used in M/40, these guns tended to crack when fired 9mm "submachinegun" ammunition, and also M/40 were less reliable than original L-35s, so in the 1980s almost all M/40s were recalled from military service and replaced by older m/07 pistol (licensed Browning M1903 pistols) as an emergency feature. Later, Sweden forces adopted the Glock 17 as a standard service sidearm.

Thechically, L-35 is a recoil operted, locked breech pistol. It uses short recoiling barrel with barrel extension of rectangular cross-shape. Inside that extension the bolt is located, also of squared cross-section. Bolt and barrel extension are intrlocked by wertically movable locking lug, which is cammed out of engagement when hitting the frame after a short recoil. The L-35 is a concealed hammer fired, single action gun, that featured manual safety at the left side of the frame. On the top of the barrel extension there is a loaded chamber indicator. another intersting feature of the L-35 is a bolt accelerator, which gives to the bolt additional energy to operate in extreme cold or dirt.

The Husqvarna M/40 was diifferent from the L-35 in some respects: first, it has larger trigger guard; second, M/40 had no loaded chamber indicator; third, and most important, M/40 lacked the bolt accelerator, which lead to the decreased reliability. The backstrap of the grip of M/40 also had been cut for removable shoulder stock / holster. The M/40 pistol had been manufactured during the 1940-1946, with total of less than 100.000 pistos.

On the other hand, the original L-35 was extremely reliable and robust gun, with the only drawback of being slightly too heavy.

Read more »

Shevchenko PSh-4

Shevchenko PSh-4 pistol

Type	Double Action semiautomatic
Caliber(s)	9x18 Makarov
Weight unloaded	900 g
Length	172 mm
Barrel length	142 mm
Magazine capacity	15 rounds

The most intriguing small arms “producer” in Ukraine was the KB-ST (Design Bureau for Special Techniques). This highly controversial organization was established in 1993 and during the late nineties announced a series of a “revolutionary” small arms designs, such as sub-machine guns and sniper rifles of outstanding, if not unbelievable, characteristics. However, no foreign experts ever were able to test these “wonder weapons”, and by now it seems that KB-ST has folded and gone out of business. One of such wonder weapons widely advertised in Ukrainian literature as “unique” and “superior” was the Pistolet Shevchenko, or PSh in short. This overly complicated and strange-looking weapon was also an amalgam of previously known ideas, some of which were tried and rejected 50 or even 100 years ago. To start with, the PSh used a two-stage feed system, borrowed from the 1900-period Gabbet-Fairfax “Mars” pistol of British origin. This system, in which the cartridge is first pulled back from the magazine and placed on a lifter, then raised inline with the barrel and fed forward and into the chamber, was necessary because of the elongated barrel, which protruded back into the action. To further complicate the construction, its designer Shevchenko used a very rare gas-operated locking system first (and probably last) used in a WW2-era prototype Horn assault rifle from Germany. This system employs two small gas pistons that are forced by gas pressure sideways from the frame and into locking recesses in the slide. Another strange feature was a hand-cocking device, probably taken from HK P7 pistol, but in a twist – instead of full-hand cocking lever PSh employed some form of a second trigger, located below the “primary” trigger and used to cock the striker when pressed by one middle finger. If you still not have enough of this design, it also had a ribbed, aluminium jacket on the barrel, and a very special sort of slide stop, that locked slide open once there was ONE cartridge left in the gun. The claimed purpose of this arrangement was to allow shooter to make its “deliberate last shot” – in its own head, probably. Not surprisingly, this weapon, “available” in 9x18 PM, 9x19 and .45 ACP, never went past magazine pages, and probably, a handful of prototypes. Nevertheless, the author decided to include it, if just for the amusement of the readers.

Read more »

Fort 17

Fort 17 pistol, presentation version with engraved and gold-inlaid slide



Type	Double Action semiautomatic
Caliber(s)	9x18 PM / Makarov
Weight unloaded	700 g
Length	180 mm
Barrel length	95 mm
Magazine capacity	12 rounds

Fort 17 pistol is the latest development of the Ukrainian state-owned FORT factory. Basically, it is a polymer-framed modification of the earlier Fort 12 pistol, and all the mechanisms and properties are almost the same between these two pistols. However, the Fort 17 is lighter than its predecessor, and features a removable grip backstrap, which can be had in various sizes, to adopt the pistol for a particular shooter. For description of mechanisms, please refer to Fort 12 entry at this site.

Read more »

Fort-15

Fort-15 pistol



Type	Double Action semiautomatic
Caliber(s)	9x19 Luger
Weight unloaded	730 g
Length	190 mm
Barrel length	108 mm
Magazine capacity	16 rounds

Fort-15 pistol was first announced in 2007 by state-owned Ukrainian organization Fort, which supplies arms and equipment to Ukrainian law enforcement organizations. The future of this pistol is still uncertain, as recently its manufacturer obtained license rights from Israel to manufacture Jericho pistols in same caliber.

The Fort-15 pistol is short recoil operated, locked breech pistol which uses Browning HP-type locking. It features polymer frame double action trigger with exposed hammer and frame-mounted manual safety.

Read more »

Fort 14

Fort 14 pistol

Fort 14 pistol cross-section diagram

Type	Double Action semiautomatic
Caliber(s)	9x18 mm PM/Makarov
Weight unloaded	920 g
Length	222 mm
Barrel length	135 mm
Magazine capacity	14 rounds

The Fort 14 pistol has been developed by the 2003 at the state-owned FORT factory for Ukrainian security and police forces. In attempt to produce more powerful weapon, than the earlier 9x18mm PM Fort 12 pistol, the Fort 14 has been initially designed for the more powerful 9x19 Luger / Parabellum ammunition, and thus has locked breech design with longer barrel. Later on, designers switched back to the less powerful 9x18 PM/Makarov ammunition, which usually does not require locked breech system, so new pistol has been redesigned with the plain blowback system. However, it retained the easily detachable barrel, usually typical for locked breech, recoil operated designs. Compared to the Fort 12, the Fort 14 has significantly longer barrel and sight radius, both resulting in improved accuracy, and slightly increased magazine capacity. SA special "tactical" version of the Fort 14 is produced, with extended threaded barrel, which can accept a silencer, and with the accessory rail for light or laser on the frame, under the barrel. First production Fort 14 pistols went to selected units in Ukrainian police in 2003.

The Fort 14 pistol is a blowback operated, semiautomatic pistol of all-steel construction. The trigger is of double action  type, with exposed hammer. The manual safety switch is located at the left side of the slide, and can lock the hammer in cocked or lowered position. Double action magazine holds 14 rounds of ammunition, magazine release button is located at the left side of the trigger guard base.

Read more »

Fort 12

Fort 12 pistol, right side view



Same pistol, left side, slide stop engaged

Fort 12 pistol in the presentation finish

Fort 12 pistol, partially disassembled

Type: Double Action, semiautomatic
Caliber: 9x18mm Makarov
Weight: 830 g empty
Length: 180 mm
Barrel length: 95 mm
Capacity: 12 rounds

The Fort 12 pistol is an attempt of the independent Ukraine (one of the former USSR republics) to develop its own police pistol to replace Soviet era, aging Makarov PM pistols. To accomplish this task, Ukrainian state-owned FORT factory purchased Czech machinery from CZ-Uhersky Brod factory, and by the late 1990s developed its first pistol, the Fort 12. Currently, this gun is issued to the Ukrainian police and security forces and also sold on civilian market chambered for non-lethal rubber ammunition or tear gas ammunition. early production Fort 12 pistols were reported as only marginally reliable, but at the present time most of the teething problems are gone, and Fort 12 pistol provides some improvements over the older Makarov PM in the ergonomics, accuracy and magazine capacity. The only visible minor flaw of the Fort 12 design is the lack of the safe decocking facility.

The Fort 12 is a blowback operated, double action pistol. Frame and slide are made from steel. Manual safety is mounted on the left side of the slide only, and locks the hammer either in cocked or in lowered position. Guns are manufactured in standard grade with mated finish, or in presentational grade, with gold inlays and engravings. Magazine is of double column type, and holds 12 rounds of ammunition, magazine release button is located at the base of the trigger guard, on the left side of the frame.

Read more »
